The Outdoor Rental LED Display Panel

Short Description:

Outdoor Rental LED display refers to renting a LED display that utilizes LED technology. LED has become today’s standard for display technology due to its superior brightness, color contrast and energy efficiency.

For the LED rental display, it is usually made of die-casting aluminum cabinet, the structure is light and thin, the stability is high, it i convenient to install and disassemble at any time, suitable for holding concerts and stage performances.

Outdoor rental LED display need to be moved frequently, repeatedly disassembled and installed, so the requirements for products are high, and the product shape design, structural design, material selection are all stressful. For example, if a concert is finished, it can be disassembled and transported to the other one in a limited time.

Send email to us Send email WhatsApp

Product Detail

Parameters

Application

Product Tags

With a convenient lightweight of 8.5k for 500x1000 cabinet, the outdoor LED display screen is easy to transport and install. Die-casting aluminum body makes it safe and stable.

The outdoor LED display screen consists of IP65 waterproof processes to ensure high quality and usage outdoors. Parts with waterproof are as followed:

●  LED Lamp
●  Power Connector
●  Signal Connector
●  PCB Board

The outdoor LED display screen contains Nationstar SMD1921 with high brightness up to 6000nits. The brightness is adjustable from 1000nits to 6000nits.

Advantages of The Outdoor Rental LED Display

Slim and lightweight design.

Fast lock design, fast connection.

Concave or convex installation with curved locks.

High quality CNC die-casting design, seamless splicing.

Two size cabinet design, meeting with different requirement.

High refresh rate and grayscale, providing excellent and vivid images.

Wide viewing angle, clear and visible images, attracting more audiences.

Previous: The Indoor Rental LED Display Panel

Next: The Indoor Fine Pixel Pitch LED Display/HD LED Display

Item	Outdoor P2.6	Outdoor P3.91	Outdoor P4.81
Pixel Pitch	2.6mm	3.91mm	4.81mm
Module size	250mmx250mm
lamp size	SMD1515	SMD1921	SMD1921
Module resolution	96*96dots	64*64dots	52*52dots
Module weight	0.35kgs
Cabinet size	500x500mm and 500x1000mm
Cabinet resolution	192192dots/192384dots	128128dots/128256dots	104104dots/104208dots
Pixel density	147456dots/sqm	65536dots/sqm	43264dots/sqm
Recommended viewing distance	2m	3m	4m
Material	Die-Casting Aluminum
Cabinet Weight	10kgs
Brightness	≥4500cd/㎡
Refresh rate	≥3840Hz
Processing depth	16 bits
Gray Scale	65536 levels per color
Color	281.4 trillion
Input Voltage	AC220V/50Hz or AC110V/60Hz
Imput Power Frequency	50-60Hz
Power Consumption(Max. / Ave.)	660/220 W/m2
IP rating(Front/Rear)	IP65
Maintenance	Rear Service
Data Interconnection	Cat 5 Cable(L<100M); Multi-mode fiber (L<300M);single mode fiber (L<15km)
Operating Temperature	-40°C-+60°C
Operating Humidity	10-90% RH
Operating Life	100,000 Hours
