Indoor Fixed LED Display for permanent installation
Parameters
| Item | Indoor P1.5 | Indoor P2.0 | Indoor P2.5 |
| Pixel Pitch | 1.538mm | 2.0mm | 2.5mm |
| Module size | 320mmx160mm | ||
| lamp size | SMD1010 | SMD1515 | SMD2020 |
| Module resolution | 208*104dots | 160*80dots | 128*64dots |
| Module weight | 0.25kgs | ||
| Cabinet size | 640x480mm | ||
| Cabinet resolution | 416*312dots | 320*240dots | 256*192dots |
| Module quanity | |||
| Pixel density | 422500dots/sqm | 250000dots/sqm | 160000dots/sqm |
| Material | Die-Casting Aluminum | ||
| Cabinet Weight | 9kgs | ||
| Brightness | ≥800cd/㎡ | ||
| Refresh rate | ≥3840Hz | ||
| Input Voltage | AC220V/50Hz or AC110V/60Hz | ||
| Power Consumption(Max. / Ave.) | 660/220 W/m2 | ||
| IP rating(Front/Rear) | IP30 | ||
| Maintenance | Front Service | ||
| Operating Temperature | -40°C-+60°C | ||
| Operating Humidity | 10-90% RH | ||
| Operating Life | 100,000 Hours | ||
640*480mm Mini LED Display is designed with a 4:3 ratio. The 4:3 resolution is used for panels in the command center. This fine pixel pitch LED display screen is the perfect substitute for an LCD display screen. A die-cast aluminum cabinet ensures a flat and seamless screen. Not to mention the color uniformity, a dot-to-dot correction technology delivers tremendous visual enjoyment of a pure image with great gradation.
We also design the different size in order to adopt to your different screen requirement. All of them are adapted to each other and can join with each other.
Advantages of Our Indoor Fixed LED Display
In case of failure, it can be easily maintained.
High precision, solid and reliable frame design.
Quick installation and disassembly, saving working time and labor cost.
High refresh rate and grayscale, providing excellent and vivid images.
Wide viewing angle, clear and visible images, attracting more audiences.
Flexible adaptation to various applications and creative settings for specific activities.
